Image is for reference only , See Product Specifications
0398900620
| Manufacturers: | Molex |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | 0398900620 |
| Description: | TERM BLK 10P SIDE ENTRY 5MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Black |
| Pitch | 0.197" (5.00mm) |
| Series | Eurostyle 39890 |
| Current | 17.5A |
| Voltage | 150V |
| Features | - |
| Packaging | Bulk |
| Wire Gauge | 12-30 AWG |
| Part Status | Active |
| Screw Thread | M3 |
| Mounting Type | Through Hole |
| Torque - Screw | - |
| Number of Levels | 2 |
| Wire Termination | Screw |
| Mating Orientation | Horizontal with Board |
| Dielectric Material | Polyamide (PA), Nylon |
| Positions Per Level | 10 |
| Operating Temperature | 105°C |
| Clamp Material - Plating | Brass - Nickel Plated |
| Screw Material - Plating | Bronze - Nickel Plated |
| Contact Material - Plating | Phosphor Bronze - Tin Plated |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $5.86 | $5.74 | $5.63 |
