Image is for reference only , See Product Specifications
0398800304
| Manufacturers: | Molex |
|---|---|
| Product Category: | Terminal Blocks - Wire to Board |
| Data Sheet: | 0398800304 |
| Description: | TERM BLK 4P SIDE ENT 5.08MM PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Molex |
| Product Category | Terminal Blocks - Wire to Board |
| Color | Black |
| Pitch | 0.200" (5.08mm) |
| Series | Eurostyle 39880 |
| Current | 13.5A |
| Voltage | 300V |
| Features | Interlocking (Side) |
| Packaging | Bulk |
| Wire Gauge | 16-30 AWG |
| Part Status | Active |
| Screw Thread | M3 |
| Mounting Type | Through Hole |
| Torque - Screw | 0.68 Nm (6 Lb-In) |
| Number of Levels | 1 |
| Wire Termination | Screw - Rising Cage Clamp |
| Mating Orientation | Horizontal with Board |
| Dielectric Material | Polyamide (PA), Nylon |
| Positions Per Level | 4 |
| Operating Temperature | -40°C ~ 105°C |
| Clamp Material - Plating | Copper Alloy - Nickel Plated |
| Screw Material - Plating | Copper Alloy - Nickel Plated |
| Contact Material - Plating | Copper Alloy - Tin Plated |
In Stock 209 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.52 | $1.49 | $1.46 |
