Image is for reference only , See Product Specifications
TN2124K1-G
| Manufacturers: | Microchip Technology |
|---|---|
| Product Category: | Transistors - FETs, MOSFETs - Single |
| Data Sheet: | TN2124K1-G |
| Description: | MOSFET N-CH 240V 0.134A SOT23-3 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Microchip Technology |
| Product Category | Transistors - FETs, MOSFETs - Single |
| Series | - |
| FET Type | N-Channel |
| Packaging | Digi-Reel® |
| Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Vgs(th) (Max) @ Id | 2V @ 1mA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 15Ohm @ 120mA, 4.5V |
| Power Dissipation (Max) | 360mW (Tc) |
| Supplier Device Package | TO-236AB (SOT23) |
| Drain to Source Voltage (Vdss) | 240V |
| Input Capacitance (Ciss) (Max) @ Vds | 50pF @ 25V |
| Current - Continuous Drain (Id) @ 25°C | 134mA (Tj) |
| Drive Voltage (Max Rds On, Min Rds On) | 3V, 4.5V |
In Stock 3464 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
