Image is for reference only , See Product Specifications
TC4421AVAT
| Manufacturers: | Microchip Technology |
|---|---|
| Product Category: | PMIC - Gate Drivers |
| Data Sheet: | TC4421AVAT |
| Description: | IC MOSFET DRIVER 9A INV TO220-5 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Microchip Technology |
| Product Category | PMIC - Gate Drivers |
| Series | - |
| Gate Type | IGBT, N-Channel, P-Channel MOSFET |
| Packaging | Tube |
| Input Type | Inverting |
| Part Status | Active |
| Channel Type | Single |
| Mounting Type | Through Hole |
| Package / Case | TO-220-5 |
| Base Part Number | TC4421A |
| Voltage - Supply | 4.5V ~ 18V |
| Number of Drivers | 1 |
| Driven Configuration | Low-Side |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Rise / Fall Time (Typ) | 38ns, 33ns |
| Supplier Device Package | TO-220-5 |
| Logic Voltage - VIL, VIH | 0.8V, 2.4V |
| Current - Peak Output (Source, Sink) | 10A, 10A |
In Stock 2442 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.43 | $2.38 | $2.33 |
Request Quote
