Image is for reference only , See Product Specifications
MCP4801-E/MC
| Manufacturers: | Microchip Technology |
|---|---|
| Product Category: | Data Acquisition - Digital to Analog Converters (DAC) |
| Data Sheet: | MCP4801-E/MC |
| Description: | IC DAC 8BIT V-OUT 8DFN |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Microchip Technology |
| Product Category | Data Acquisition - Digital to Analog Converters (DAC) |
| Series | - |
| Packaging | Tube |
| Output Type | Voltage - Buffered |
| Part Status | Active |
| Architecture | String DAC |
| INL/DNL (LSB) | ±0.25, ±0.2 |
| Mounting Type | Surface Mount |
| Settling Time | 4.5µs (Typ) |
| Data Interface | SPI |
| Number of Bits | 8 |
| Package / Case | 8-VFDFN Exposed Pad |
| Reference Type | Internal |
| Base Part Number | MCP4801 |
| Differential Output | No |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | 8-DFN (2x3) |
| Number of D/A Converters | 1 |
| Voltage - Supply, Analog | 2.7V ~ 5.5V |
| Voltage - Supply, Digital | 2.7V ~ 5.5V |
In Stock 414 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $1.16 | $1.14 | $1.11 |
Request Quote
