Image is for reference only , See Product Specifications
G6015M12B1-RGR-EM
| Manufacturers: | Mechatronics Fan Group |
|---|---|
| Product Category: | DC Brushless Fans (BLDC) |
| Data Sheet: | G6015M12B1-RGR-EM |
| Description: | FAN AXIAL 60X15.3MM 12VDC WIRE |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Mechatronics Fan Group |
| Product Category | DC Brushless Fans (BLDC) |
| RPM | 4000 RPM |
| Noise | 28.0 dB(A) |
| Width | 15.30mm |
| Series | G6015-G |
| Weight | 0.059 lb (26.76 g) |
| Air Flow | 16.0 CFM (0.448m³/min) |
| Fan Type | Tubeaxial |
| Features | Speed Sensor (Tach), Thermal Overload Protector (TOP) |
| Approvals | CE, cUL, TUV, UL |
| Part Status | Active |
| Termination | 3 Wire Leads |
| Bearing Type | Ball |
| Voltage Range | - |
| Static Pressure | 0.150 in H2O (37.3 Pa) |
| Voltage - Rated | 12VDC |
| Lifetime @ Temp. | - |
| Material - Blade | Polybutylene Terephthalate (PBT) |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Size / Dimension | Square - 60mm L x 60mm H |
| Ingress Protection | IP57 - Dust Protected, Waterproof |
| Current Rating (Amps) | 0.110A |
| Operating Temperature | - |
In Stock 5 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $16.41 | $16.08 | $15.76 |
