Image is for reference only , See Product Specifications
SSL-LX2579IGW
| Manufacturers: | Lumex Opto/Components Inc. |
|---|---|
| Product Category: | LED Indication - Discrete |
| Data Sheet: | SSL-LX2579IGW |
| Description: | LED GRN/RED DIFF RECT 2X5MM T/H |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Lumex Opto/Components Inc. |
| Product Category | LED Indication - Discrete |
| Color | Green, Red |
| Series | - |
| Features | - |
| Lens Size | 5.00mm x 2.00mm |
| Packaging | Bulk |
| Lens Color | White |
| Lens Style | Rectangle with Flat Top |
| Part Status | Active |
| Height (Max) | 10.50mm |
| Configuration | Common Cathode |
| Mounting Type | Through Hole |
| Viewing Angle | 110° |
| Current - Test | 20mA Green, 20mA Red |
| Package / Case | Radial - 3 Leads |
| Size / Dimension | - |
| Lens Transparency | Diffused |
| Wavelength - Peak | 565nm Green, 635nm Red |
| Millicandela Rating | 8mcd Green, 14mcd Red |
| Wavelength - Dominant | - |
| Supplier Device Package | Rectangular 2mmx5mm |
| Voltage - Forward (Vf) (Typ) | 2.1V Green, 2.1V Red |
In Stock 722 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.67 | $0.66 | $0.64 |
