Image is for reference only , See Product Specifications
VTP175LF
| Manufacturers: | Littelfuse Inc. |
|---|---|
| Product Category: | PTC Resettable Fuses |
| Data Sheet: | VTP175LF |
| Description: | PTC RESET FUSE 16V 1.75A STRAP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Littelfuse Inc. |
| Product Category | PTC Resettable Fuses |
| Type | Polymeric |
| Series | PolySwitch®, VTP |
| Ratings | - |
| Approvals | CSA, TUV, UL |
| Part Status | Active |
| Lead Spacing | - |
| Time to Trip | 5s |
| Current - Max | 100A |
| Mounting Type | User Defined |
| Voltage - Max | 16V |
| Package / Case | Strap |
| Thickness (Max) | 0.032" (0.80mm) |
| Size / Dimension | 1.063" L x 0.146" W (27.00mm x 3.70mm) |
| Current - Trip (It) | 3.6A |
| Height - Seated (Max) | - |
| Operating Temperature | -40°C ~ 85°C |
| Current - Hold (Ih) (Max) | 1.75A |
| Resistance - Initial (Ri) (Min) | 29 mOhms |
| Resistance - Post Trip (R1) (Max) | 102 mOhms |
In Stock 7000 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.29 | $0.28 | $0.28 |
