Image is for reference only , See Product Specifications
RGEF1400-2
| Manufacturers: | Littelfuse Inc. |
|---|---|
| Product Category: | PTC Resettable Fuses |
| Data Sheet: | RGEF1400-2 |
| Description: | PTC RESET FUSE 16V 14A RADIAL |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Littelfuse Inc. |
| Product Category | PTC Resettable Fuses |
| Type | Polymeric |
| Series | PolySwitch®, RGEF |
| Ratings | - |
| Approvals | CSA, TUV, UL |
| Part Status | Active |
| Lead Spacing | 0.400" (10.15mm) |
| Time to Trip | 9s |
| Current - Max | 100A |
| Mounting Type | Through Hole |
| Voltage - Max | 16V |
| Package / Case | Radial, Disc |
| Thickness (Max) | - |
| Size / Dimension | 0.925" L x 0.114" W (23.50mm x 2.90mm) |
| Current - Trip (It) | 23.8A |
| Height - Seated (Max) | 1.098" (27.90mm) |
| Operating Temperature | -40°C ~ 85°C |
| Current - Hold (Ih) (Max) | 14A |
| Resistance - Initial (Ri) (Min) | 2.6 mOhms |
| Resistance - Post Trip (R1) (Max) | 6.4 mOhms |
In Stock 2000 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.44 | $0.43 | $0.42 |
