Image is for reference only , See Product Specifications
MINISMDC010-02
| Manufacturers: | Littelfuse Inc. |
|---|---|
| Product Category: | PTC Resettable Fuses |
| Data Sheet: | MINISMDC010-02 |
| Description: | PTC RESET FUSE 60V 100MA 1812 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Littelfuse Inc. |
| Product Category | PTC Resettable Fuses |
| Type | Polymeric |
| Series | PolySwitch®, miniSMD |
| Ratings | - |
| Approvals | CSA, TUV, UL |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Lead Spacing | - |
| Time to Trip | 5s |
| Current - Max | 40A |
| Mounting Type | Surface Mount |
| Voltage - Max | 60V |
| Package / Case | 1812 (4532 Metric), Concave |
| Thickness (Max) | 0.035" (0.89mm) |
| Size / Dimension | 0.179" L x 0.128" W (4.55mm x 3.24mm) |
| Current - Trip (It) | 300mA |
| Height - Seated (Max) | - |
| Operating Temperature | -40°C ~ 85°C |
| Current - Hold (Ih) (Max) | 100mA |
| Resistance - Initial (Ri) (Min) | 700 mOhms |
| Resistance - Post Trip (R1) (Max) | 12.7 Ohms |
