Image is for reference only , See Product Specifications
LVR008NS-2
| Manufacturers: | Littelfuse Inc. |
|---|---|
| Product Category: | PTC Resettable Fuses |
| Data Sheet: | LVR008NS-2 |
| Description: | PTC RESET FUSE 240V 80MA RADIAL |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Littelfuse Inc. |
| Product Category | PTC Resettable Fuses |
| Type | Polymeric |
| Series | PolySwitch®, LVR |
| Ratings | - |
| Approvals | CQC, CSA, TUV, UL |
| Packaging | Cut Tape (CT) |
| Part Status | Active |
| Lead Spacing | 0.200" (5.08mm) |
| Time to Trip | 10s |
| Current - Max | 1.2A |
| Mounting Type | Through Hole |
| Voltage - Max | 240V (265V Int) |
| Package / Case | Radial, Disc |
| Thickness (Max) | - |
| Size / Dimension | 0.283" Dia x 0.181" T (7.20mm x 4.60mm) |
| Current - Trip (It) | 190mA |
| Height - Seated (Max) | 0.402" (10.20mm) |
| Operating Temperature | -20°C ~ 85°C |
| Current - Hold (Ih) (Max) | 80mA |
| Resistance - Initial (Ri) (Min) | 7.4 Ohms |
| Resistance - Post Trip (R1) (Max) | 26 Ohms |
In Stock 2762 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.74 | $0.73 | $0.71 |
