Image is for reference only , See Product Specifications
ASMD050F-2
| Manufacturers: | Littelfuse Inc. |
|---|---|
| Product Category: | PTC Resettable Fuses |
| Data Sheet: | ASMD050F-2 |
| Description: | PTC RESET FUSE 60V 370MA 2SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Littelfuse Inc. |
| Product Category | PTC Resettable Fuses |
| Type | Polymeric |
| Series | PolySwitch®, ASMD |
| Ratings | AEC-Q200 |
| Approvals | - |
| Packaging | Cut Tape (CT) |
| Part Status | Active |
| Lead Spacing | - |
| Time to Trip | 20s |
| Current - Max | 10A |
| Mounting Type | Surface Mount |
| Voltage - Max | 60V |
| Package / Case | 2-SMD |
| Thickness (Max) | 0.125" (3.18mm) |
| Size / Dimension | 0.290" L x 0.202" W (7.36mm x 5.12mm) |
| Current - Trip (It) | 940mA |
| Height - Seated (Max) | - |
| Operating Temperature | -40°C ~ 85°C |
| Current - Hold (Ih) (Max) | 370mA |
| Resistance - Initial (Ri) (Min) | 290 mOhms |
| Resistance - Post Trip (R1) (Max) | 1.4 Ohms |
In Stock 3354 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.85 | $0.83 | $0.82 |
