30ST350U
| Manufacturers: | Littelfuse Inc. |
|---|---|
| Product Category: | PTC Resettable Fuses |
| Data Sheet: | 30ST350U |
| Description: | PTC RESET FUSE 30V 3.5A STRAP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Littelfuse Inc. |
| Product Category | PTC Resettable Fuses |
| Type | Polymeric |
| Series | POLY-FUSE®, ST |
| Ratings | - |
| Approvals | cURus, TUV |
| Packaging | Bulk |
| Part Status | Active |
| Lead Spacing | - |
| Time to Trip | 3s |
| Current - Max | 100A |
| Mounting Type | User Defined |
| Voltage - Max | 30V |
| Package / Case | Strap |
| Thickness (Max) | 0.043" (1.10mm) |
| Size / Dimension | 1.185" L x 0.522" W (30.10mm x 13.25mm) |
| Current - Trip (It) | 6.3A |
| Height - Seated (Max) | - |
| Operating Temperature | -40°C ~ 85°C |
| Current - Hold (Ih) (Max) | 3.5A |
| Resistance - Initial (Ri) (Min) | 17 mOhms |
| Resistance - Post Trip (R1) (Max) | 31 mOhms |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.42 | $0.41 | $0.40 |
