Image is for reference only , See Product Specifications
048501.5DR
| Manufacturers: | Littelfuse Inc. |
|---|---|
| Product Category: | Fuses |
| Data Sheet: | 048501.5DR |
| Description: | FUSE BOARD MNT 1.5A 600VDC 2SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Littelfuse Inc. |
| Product Category | Fuses |
| Color | - |
| Series | 485 |
| Approvals | CSA, UL |
| Fuse Type | Board Mount (Cartridge Style Excluded) |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Melting I²t | 0.392 |
| Mounting Type | Surface Mount |
| Response Time | Fast Blow |
| Package / Case | 2-SMD, Square End Block |
| Size / Dimension | 0.476" L x 0.177" W x 0.177" H (12.10mm x 4.50mm x 4.50mm) |
| DC Cold Resistance | 0.3917 Ohms |
| Voltage Rating - DC | 600V |
| Current Rating (Amps) | 1.5A |
| Operating Temperature | -55°C ~ 125°C |
| Breaking Capacity @ Rated Voltage | 100A |
In Stock 1500 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.33 | $2.28 | $2.24 |
