015401.5DR
| Manufacturers: | Littelfuse Inc. |
|---|---|
| Product Category: | Fuses |
| Data Sheet: | 015401.5DR |
| Description: | FUSE BRD MNT 1.5A 125VAC/VDC SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Littelfuse Inc. |
| Product Category | Fuses |
| Color | - |
| Series | OMNI-BLOK® 154 |
| Approvals | PSE, UL |
| Fuse Type | Board Mount (Cartridge Style Excluded) |
| Packaging | Digi-Reel® |
| Part Status | Active |
| Melting I²t | 0.853 |
| Mounting Type | Holder, Surface Mount |
| Response Time | Fast Blow |
| Package / Case | 2-SMD, Square End Block with Holder |
| Size / Dimension | 0.383" L x 0.198" W x 0.150" H (9.73mm x 5.03mm x 3.81mm) |
| DC Cold Resistance | 0.063 Ohms |
| Voltage Rating - AC | 125V |
| Voltage Rating - DC | 125V |
| Current Rating (Amps) | 1.5A |
| Operating Temperature | -55°C ~ 125°C |
| Breaking Capacity @ Rated Voltage | 50A |
In Stock 4541 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
