Image is for reference only , See Product Specifications
28T0119-00P
| Manufacturers: | Laird - Signal Integrity Products |
|---|---|
| Product Category: | Ferrite Cores |
| Data Sheet: | 28T0119-00P |
| Description: | FERRITE CORE TOROID 3.07MM OD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Laird - Signal Integrity Products |
| Product Category | Ferrite Cores |
| Gap | Ungapped |
| Width | - |
| Finish | Parylene |
| Height | 1.27mm |
| Length | - |
| Series | - |
| Diameter | 3.05mm |
| Material | 28 |
| Core Type | Toroid |
| Tolerance | ±20% |
| Part Status | Active |
| Core Factor (ΣI/A) mm | 5.651 |
| Inductance Factor (Al) | 189nH |
| Supplier Device Package | - |
| Effective Area (Ae) mm² | 1.06 |
| Effective Length (le) mm | 5.988 |
| Initial Permeability (µi) | 850 |
| Effective Magnetic Volume (Ve) mm³ | 6.345 |
In Stock 95878 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.10 | $0.10 | $0.10 |
