Image is for reference only , See Product Specifications
FHG.0K.302.CLAC45
| Manufacturers: | LEMO |
|---|---|
| Product Category: | Circular Connectors |
| Data Sheet: | FHG.0K.302.CLAC45 |
| Description: | CONN PLUG MALE 2POS SOLDER CUP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | LEMO |
| Product Category | Circular Connectors |
| Color | Silver |
| Series | 0K |
| Features | Backshell |
| Packaging | Bulk |
| Shielding | Shielded |
| Orientation | G |
| Part Status | Active |
| Termination | Solder Cup |
| Applications | - |
| Shell Finish | Chrome |
| Cable Opening | 0.161" ~ 0.177" (4.10mm ~ 4.50mm) |
| Mounting Type | Free Hanging (In-Line), Right Angle |
| Connector Type | Plug, Male Pins |
| Fastening Type | Push-Pull |
| Shell Material | Brass |
| Voltage Rating | - |
| Insert Material | Polyetheretherketone (PEEK) |
| Shell Size, MIL | - |
| Contact Material | Brass |
| Mounting Feature | - |
| Ingress Protection | IP66/68 - Dust Tight, Water Resistant, Waterproof |
| Number of Positions | 2 |
| Shell Size - Insert | 302 |
| Current Rating (Amps) | 10A |
| Operating Temperature | -55°C ~ 200°C |
| Contact Finish - Mating | Gold |
| Backshell Material, Plating | Brass, Chrome |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Mating | 39.4µin (1.00µm) |
In Stock 6 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $118.72 | $116.35 | $114.02 |
