| Manufacturer |
Kingbright |
| Product Category |
LED Indication - Discrete |
| Color |
Red, Green, Blue (RGB) |
| Series |
HELI Colour |
| Features |
- |
| Lens Size |
2.00mm x 1.00mm |
| Packaging |
Digi-Reel® |
| Lens Color |
Colorless |
| Lens Style |
Rectangle with Domed Top |
| Part Status |
Active |
| Height (Max) |
1.20mm |
| Configuration |
Common Anode |
| Mounting Type |
Surface Mount, Right Angle |
| Viewing Angle |
120° |
| Current - Test |
20mA Red, 20mA Green, 20mA Blue |
| Package / Case |
4-SMD, No Lead |
| Size / Dimension |
3.00mm L x 1.50mm W |
| Lens Transparency |
Clear |
| Wavelength - Peak |
630nm Red, 515nm Green, 460nm Blue |
| Millicandela Rating |
140mcd Red, 500mcd Green, 70mcd Blue |
| Wavelength - Dominant |
621nm Red, 525nm Green, 465nm Blue |
| Supplier Device Package |
4-SMD |
| Voltage - Forward (Vf) (Typ) |
2V Red, 3.3V Green, 3.3V Blue |
