Image is for reference only , See Product Specifications
1223
| Manufacturers: | Keystone Electronics |
|---|---|
| Product Category: | Terminals - PC Pin, Single Post Connectors |
| Data Sheet: | 1223 |
| Description: | CONN PC PIN CIRC 0.093DIA NICKEL |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Keystone Electronics |
| Product Category | Terminals - PC Pin, Single Post Connectors |
| Series | - |
| Packaging | Bulk |
| Insulation | Non-Insulated |
| Part Status | Active |
| Termination | Staking Flare |
| Mounting Type | Through Hole |
| Terminal Type | PC Pin |
| Contact Finish | Nickel |
| Terminal Style | Single End |
| Board Thickness | 0.062" (1.57mm) or 0.093" (2.36mm) |
| Flange Diameter | 0.125" (3.18mm) |
| Contact Material | Brass |
| Insulation Color | - |
| Length - Overall | 0.418" (10.62mm) |
| Length - Above Flange | 0.267" (6.78mm) |
| Length - Below Flange | 0.125" (3.18mm) |
| Material - Insulation | - |
| Mounting Hole Diameter | - |
| Pin Size - Above Flange | 0.093" (2.36mm) Dia |
| Pin Size - Below Flange | 0.093" (2.36mm) Dia |
| Contact Finish Thickness | - |
In Stock 3417 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.30 | $0.29 | $0.29 |
