Image is for reference only , See Product Specifications
ALC10A331EE550
| Manufacturers: | KEMET |
|---|---|
| Product Category: | Aluminum Electrolytic Capacitors |
| Data Sheet: | ALC10A331EE550 |
| Description: | CAP ALUM 330UF 20% 550V SNAP-IN |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | KEMET |
| Product Category | Aluminum Electrolytic Capacitors |
| Series | ALC10 |
| Ratings | - |
| Impedance | 920 mOhms |
| Packaging | Bulk |
| Tolerance | ±20% |
| Capacitance | 330µF |
| Part Status | Active |
| Applications | General Purpose |
| Lead Spacing | 0.394" (10.00mm) |
| Polarization | Polar |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Voltage - Rated | 550V |
| Lifetime @ Temp. | 18000 Hrs @ 85°C |
| Size / Dimension | 1.575" Dia (40.00mm) |
| Height - Seated (Max) | 1.850" (47.00mm) |
| Operating Temperature | -40°C ~ 85°C |
| Surface Mount Land Size | - |
| Ripple Current @ Low Frequency | 2.4A @ 100Hz |
| Ripple Current @ High Frequency | 3.9A @ 10kHz |
| ESR (Equivalent Series Resistance) | 1.056Ohm @ 100Hz |
In Stock 397 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $19.65 | $19.26 | $18.87 |
Request Quote
