Image is for reference only , See Product Specifications
MM70-314-310B1-1-R300
| Manufacturers: | JAE Electronics |
|---|---|
| Product Category: | Card Edge Connectors - Edgeboard Connectors |
| Data Sheet: | MM70-314-310B1-1-R300 |
| Description: | CONN MXM FMALE 314POS 0.020 GOLD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | JAE Electronics |
| Product Category | Card Edge Connectors - Edgeboard Connectors |
| Color | Black |
| Pitch | 0.020" (0.50mm) |
| Gender | Female |
| Series | MM70 |
| Features | Board Guide, Latches |
| Read Out | Dual |
| Card Type | MXM 3.0 |
| Packaging | Cut Tape (CT) |
| Part Status | Active |
| Termination | Solder |
| Contact Type | - |
| Mounting Type | Surface Mount, Right Angle |
| Card Thickness | 0.047" (1.20mm) |
| Contact Finish | Gold |
| Flange Feature | - |
| Number of Rows | 2 |
| Contact Material | Copper Alloy |
| Number of Positions | 314 |
| Material - Insulation | Liquid Crystal Polymer (LCP), Glass Filled |
| Operating Temperature | -40°C ~ 85°C |
| Contact Finish Thickness | 3.94µin (0.10µm) |
| Number of Positions/Bay/Row | - |
In Stock 17026 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $7.18 | $7.04 | $6.90 |
