Image is for reference only , See Product Specifications
JN1AS10UL1
| Manufacturers: | JAE Electronics |
|---|---|
| Product Category: | Circular Connectors |
| Data Sheet: | JN1AS10UL1 |
| Description: | CONN RCPT MALE 10POS GOLD SOLDER |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | JAE Electronics |
| Product Category | Circular Connectors |
| Color | Black |
| Series | JN1 |
| Features | - |
| Packaging | Tray |
| Shielding | - |
| Orientation | N (Normal) |
| Part Status | Active |
| Termination | Solder |
| Applications | - |
| Shell Finish | - |
| Cable Opening | 0.472" (12.00mm) |
| Mounting Type | Panel Mount, Through Hole |
| Connector Type | Receptacle, Male Pins |
| Fastening Type | Push-Twist |
| Shell Material | Synthetic Resin |
| Voltage Rating | 200VAC |
| Insert Material | Synthetic Resin |
| Shell Size, MIL | - |
| Contact Material | Copper Alloy |
| Mounting Feature | Flange |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Number of Positions | 10 |
| Shell Size - Insert | S |
| Current Rating (Amps) | 3A |
| Operating Temperature | -20°C ~ 125°C |
| Contact Finish - Mating | Gold |
| Backshell Material, Plating | - |
| Material Flammability Rating | - |
| Contact Finish Thickness - Mating | 3.90µin (0.099µm) |
In Stock 231 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $4.40 | $4.31 | $4.23 |
