Image is for reference only , See Product Specifications
FF0360SA1
| Manufacturers: | JAE Electronics |
|---|---|
| Product Category: | FFC, FPC (Flat Flexible) Connectors |
| Data Sheet: | FF0360SA1 |
| Description: | CONN FPC BOTTOM 60POS 0.50MM R/A |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | JAE Electronics |
| Product Category | FFC, FPC (Flat Flexible) Connectors |
| Pitch | 0.020" (0.50mm) |
| Series | FF03 |
| Features | Zero Insertion Force (ZIF) |
| Packaging | Strip |
| Part Status | Active |
| Termination | Solder |
| Housing Color | White |
| Mating Cycles | 20 |
| Mounting Type | Surface Mount, Right Angle |
| Actuator Color | Black |
| Cable End Type | Straight |
| Contact Finish | Gold |
| Flat Flex Type | FPC |
| Voltage Rating | 50V |
| Locking Feature | Rotary Lock |
| Contact Material | Copper Alloy |
| Actuator Material | Polyamide (PA), Nylon, Glass Filled |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.079" (2.00mm) |
| Dielectric Material | Liquid Crystal Polymer (LCP) |
| Number of Positions | 60 |
| Current Rating (Amps) | 0.5A per Contact |
| Operating Temperature | -40°C ~ 85°C |
| Connector/Contact Type | Contacts, Bottom |
| Contact Finish Thickness | - |
| Material Flammability Rating | - |
In Stock 36 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $8.02 | $7.86 | $7.70 |
