Image is for reference only , See Product Specifications
DX07S024JJ2R1300
| Manufacturers: | JAE Electronics |
|---|---|
| Product Category: | USB, DVI, HDMI Connectors |
| Data Sheet: | DX07S024JJ2R1300 |
| Description: | CONN RCP USB3.1 TYPEC 24P SMD RA |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | JAE Electronics |
| Product Category | USB, DVI, HDMI Connectors |
| Gender | Receptacle |
| Series | DX07 |
| Features | Pick and Place |
| Packaging | Digi-Reel® |
| Shielding | Shielded |
| Part Status | Active |
| Termination | Solder |
| Mating Cycles | 10000 |
| Mounting Type | Surface Mount, Right Angle; Through Hole |
| Connector Type | USB - C |
| Contact Finish | Gold |
| Specifications | USB 3.1 (USB 3.1 Gen 2, Superspeed+) |
| Number of Ports | 1 |
| Voltage - Rated | 20V |
| Insulation Color | Black |
| Mounting Feature | Horizontal |
| Ingress Protection | - |
| Number of Contacts | 24 |
| Current Rating (Amps) | 0.25A, 1.25A |
| Operating Temperature | -30°C ~ 80°C |
| Shell/Shielding Material | Steel, Stainless |
| Material Flammability Rating | - |
In Stock 13464 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
Request Quote
