Image is for reference only , See Product Specifications
IR2233SPBF
| Manufacturers: | Infineon Technologies |
|---|---|
| Product Category: | PMIC - Gate Drivers |
| Data Sheet: | IR2233SPBF |
| Description: | IC DRIVER BRIDGE 3PHASE 28SOIC |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Infineon Technologies |
| Product Category | PMIC - Gate Drivers |
| Series | - |
| Gate Type | IGBT, N-Channel MOSFET |
| Packaging | Tube |
| Input Type | Inverting |
| Part Status | Active |
| Channel Type | 3-Phase |
| Mounting Type | Surface Mount |
| Package / Case | 28-SOIC (0.295", 7.50mm Width) |
| Base Part Number | IR2233SPBF |
| Voltage - Supply | 10V ~ 20V |
| Number of Drivers | 6 |
| Driven Configuration | Half-Bridge |
| Operating Temperature | 125°C (TJ) |
| Rise / Fall Time (Typ) | 90ns, 40ns |
| Supplier Device Package | 28-SOIC |
| Logic Voltage - VIL, VIH | 0.8V, 2V |
| High Side Voltage - Max (Bootstrap) | 1200V |
| Current - Peak Output (Source, Sink) | 250mA, 500mA |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $4.97 | $4.87 | $4.77 |
