Image is for reference only , See Product Specifications
IR2152S
| Manufacturers: | Infineon Technologies |
|---|---|
| Product Category: | PMIC - Gate Drivers |
| Data Sheet: | IR2152S |
| Description: | IC DRVR HALF BRDG SELF-OSC 8SOIC |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Infineon Technologies |
| Product Category | PMIC - Gate Drivers |
| Series | - |
| Gate Type | IGBT, N-Channel MOSFET |
| Packaging | Tube |
| Input Type | RC Input Circuit |
| Part Status | Obsolete |
| Channel Type | Synchronous |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Base Part Number | IR2152S |
| Voltage - Supply | 10V ~ 20V |
| Number of Drivers | 2 |
| Driven Configuration | Half-Bridge |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Rise / Fall Time (Typ) | 80ns, 40ns |
| Supplier Device Package | 8-SOIC |
| Logic Voltage - VIL, VIH | - |
| High Side Voltage - Max (Bootstrap) | 600V |
| Current - Peak Output (Source, Sink) | 125mA, 250mA |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
