Image is for reference only , See Product Specifications
EVALSF2-ICE2B765P
| Manufacturers: | Infineon Technologies |
|---|---|
| Product Category: | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
| Data Sheet: | EVALSF2-ICE2B765P |
| Description: | BOARD DEMO ICE2B765P 80W SMPS |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Infineon Technologies |
| Product Category | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS |
| Series | CoolSET®F2 |
| Board Type | Fully Populated |
| Part Status | Obsolete |
| Main Purpose | AC/DC, Primary Side |
| Power - Output | 80W |
| Voltage - Input | 85 ~ 270 VAC |
| Current - Output | 3.3A |
| Outputs and Type | 1, Isolated |
| Voltage - Output | 24V |
| Supplied Contents | Board(s) |
| Regulator Topology | Flyback |
| Utilized IC / Part | ICE2B765 |
| Frequency - Switching | 67kHz |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
