Image is for reference only , See Product Specifications
BSC014N04LSIATMA1
| Manufacturers: | Infineon Technologies |
|---|---|
| Product Category: | Transistors - FETs, MOSFETs - Single |
| Data Sheet: | BSC014N04LSIATMA1 |
| Description: | MOSFET N-CH 40V 100A TDSON-8 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Infineon Technologies |
| Product Category | Transistors - FETs, MOSFETs - Single |
| Series | OptiMOS™ |
| FET Type | N-Channel |
| Packaging | Cut Tape (CT) |
| Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | - |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerTDFN |
| Vgs(th) (Max) @ Id | 2V @ 250µA |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 1.45mOhm @ 50A, 10V |
| Power Dissipation (Max) | 2.5W (Ta), 96W (Tc) |
| Supplier Device Package | PG-TDSON-8 FL |
| Gate Charge (Qg) (Max) @ Vgs | 55nC @ 10V |
| Drain to Source Voltage (Vdss) | 40V |
| Input Capacitance (Ciss) (Max) @ Vds | 4000pF @ 20V |
| Current - Continuous Drain (Id) @ 25°C | 31A (Ta), 100A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
In Stock 9731 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.76 | $2.70 | $2.65 |
