Image is for reference only , See Product Specifications
MUBW45-12T6K
| Manufacturers: | IXYS |
|---|---|
| Product Category: | Transistors - IGBTs - Modules |
| Data Sheet: | MUBW45-12T6K |
| Description: | MODULE IGBT CBI E1 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | IXYS |
| Product Category | Transistors - IGBTs - Modules |
| Input | Three Phase Bridge Rectifier |
| Series | - |
| IGBT Type | Trench |
| Part Status | Active |
| Power - Max | 160W |
| Configuration | Three Phase Inverter with Brake |
| Mounting Type | Chassis Mount |
| NTC Thermistor | Yes |
| Package / Case | E1 |
| Base Part Number | MUBW |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Supplier Device Package | E1 |
| Vce(on) (Max) @ Vge, Ic | 3.1V @ 15V, 45A |
| Current - Collector (Ic) (Max) | 43A |
| Input Capacitance (Cies) @ Vce | 1.81nF @ 25V |
| Current - Collector Cutoff (Max) | 1.25mA |
| Voltage - Collector Emitter Breakdown (Max) | 1200V |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $54.08 | $53.00 | $51.94 |
