Image is for reference only , See Product Specifications
IXBH10N300HV
| Manufacturers: | IXYS |
|---|---|
| Product Category: | Transistors - IGBTs - Single |
| Data Sheet: | IXBH10N300HV |
| Description: | IGBT 3000V 20A 140W TO247AD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | IXYS |
| Product Category | Transistors - IGBTs - Single |
| Series | BIMOSFET™ |
| IGBT Type | - |
| Packaging | Tube |
| Input Type | Standard |
| Gate Charge | 46nC |
| Part Status | Active |
| Power - Max | 180W |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB |
| Test Condition | 960V, 10A, 10Ohm, 15V |
| Switching Energy | - |
| Td (on/off) @ 25°C | 36ns/100ns |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Supplier Device Package | TO-263 |
| Vce(on) (Max) @ Vge, Ic | 2.8V @ 15V, 10A |
| Reverse Recovery Time (trr) | 1.6µs |
| Current - Collector (Ic) (Max) | 34A |
| Current - Collector Pulsed (Icm) | 88A |
| Voltage - Collector Emitter Breakdown (Max) | 3000V |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $47.88 | $46.92 | $45.98 |
Request Quote
