Image is for reference only , See Product Specifications
H3073-01
| Manufacturers: | Harwin Inc. |
|---|---|
| Product Category: | Terminals - Turret Connectors |
| Data Sheet: | H3073-01 |
| Description: | TERM TURRET HOLLOW L=8.74-9.23MM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Harwin Inc. |
| Product Category | Terminals - Turret Connectors |
| Series | - |
| Insulation | Non-Insulated |
| Part Status | Obsolete |
| Termination | Swage |
| Mounting Type | Through Hole |
| Terminal Type | Single End, Fork, Hollow |
| Contact Finish | Tin |
| Board Thickness | 0.063" (1.60mm) |
| Flange Diameter | 0.184" ~ 0.190" (4.67mm ~ 4.83mm) |
| Staking Side ID | - |
| Staking Side OD | 0.102" ~ 0.105" (2.59mm ~ 2.67mm) |
| Contact Material | Brass Alloy |
| Insulation Color | - |
| Length - Overall | 0.443" ~ 0.463" (11.25mm ~ 11.75mm) |
| Number of Turrets | Single |
| Length - Above Board | 0.344" ~ 0.363" (8.74mm ~ 9.23mm) |
| Length - Below Flange | 0.094" ~ 0.099" (2.39mm ~ 2.51mm) |
| Material - Insulation | - |
| Diameter - Turret Head | - |
| Mounting Hole Diameter | 0.105" ~ 0.109" (2.67mm ~ 2.77mm) |
| Contact Finish Thickness | - |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
Request Quote
