G125-FV15005F2P
| Manufacturers: | Harwin Inc. |
|---|---|
| Product Category: | Rectangular Connectors - Headers, Receptacles, Female Sockets |
| Data Sheet: | G125-FV15005F2P |
| Description: | CONN RCPT 50POS 0.049 GOLD PCB |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Harwin Inc. |
| Product Category | Rectangular Connectors - Headers, Receptacles, Female Sockets |
| Style | Board to Board or Cable |
| Series | Gecko SL Reverse Fix |
| Features | Pick and Place, Polarizing Key |
| Packaging | Cut Tape (CT) |
| Part Status | Active |
| Termination | Solder |
| Applications | - |
| Contact Type | Female Socket |
| Contact Shape | Circular |
| Mounting Type | Through Hole |
| Connector Type | Receptacle |
| Fastening Type | Screw Lock |
| Number of Rows | 2 |
| Pitch - Mating | 0.049" (1.25mm) |
| Voltage Rating | 450V |
| Contact Material | Copper Alloy |
| Insulation Color | Green |
| Insulation Height | 0.207" (5.25mm) |
| Ingress Protection | - |
| Insulation Material | Polyamide (PA4T), Nylon 4T, Glass Filled, Halogen Free |
| Number of Positions | 50 |
| Row Spacing - Mating | 0.049" (1.25mm) |
| Contact Finish - Post | Gold |
| Contact Length - Post | 0.118" (3.00mm) |
| Current Rating (Amps) | 2A |
| Operating Temperature | -65°C ~ 150°C |
| Mated Stacking Heights | 7.25mm, 7.33mm |
| Contact Finish - Mating | Gold |
| Number of Positions Loaded | All |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Post | 8.00µin (0.203µm) |
| Contact Finish Thickness - Mating | 8.00µin (0.203µm) |
In Stock 50 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $52.68 | $51.63 | $50.59 |
