Image is for reference only , See Product Specifications
09663287700
| Manufacturers: | HARTING |
|---|---|
| Product Category: | D-Sub Connectors |
| Data Sheet: | 09663287700 |
| Description: | CONN DSUB PLUG 25POS PNL MNT IDC |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | HARTING |
| Product Category | D-Sub Connectors |
| Color | - |
| Series | - |
| Features | Feed Through, Grounding Indents |
| Packaging | Tray |
| Wire Gauge | - |
| Part Status | Active |
| Termination | IDC, Ribbon Cable |
| Contact Form | - |
| Contact Type | Signal |
| Mounting Type | Panel Mount |
| Connector Type | Plug, Male Pins |
| Contact Finish | - |
| Flange Feature | Housing/Shell (Unthreaded) |
| Number of Rows | 2 |
| Voltage Rating | - |
| Backset Spacing | - |
| Connector Style | D-Sub |
| Contact Material | Copper Alloy |
| Ingress Protection | - |
| Dielectric Material | Polybutylene Terephthalate (PBT), Polyester, Glass Filled |
| Number of Positions | 25 |
| Current Rating (Amps) | 2A |
| Operating Temperature | - |
| Shell Material, Finish | Steel |
| Contact Finish Thickness | - |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 3 (DB, B) |
In Stock 53 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $10.47 | $10.26 | $10.06 |
