Image is for reference only , See Product Specifications
09151072702
| Manufacturers: | HARTING |
|---|---|
| Product Category: | Circular Connectors |
| Data Sheet: | 09151072702 |
| Description: | CONN FMALE INSERT 7POS SLDR CUP |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | HARTING |
| Product Category | Circular Connectors |
| Color | - |
| Series | Han® M23 |
| Features | Insert Only, Requires Shell |
| Packaging | Bulk |
| Shielding | Unshielded |
| Orientation | - |
| Part Status | Active |
| Termination | Solder Cup |
| Applications | - |
| Shell Finish | - |
| Cable Opening | - |
| Mounting Type | - |
| Connector Type | Insert, Female Sockets |
| Fastening Type | - |
| Shell Material | - |
| Voltage Rating | 300V |
| Insert Material | Polyamide (PA), Nylon |
| Shell Size, MIL | - |
| Contact Material | - |
| Mounting Feature | - |
| Ingress Protection | - |
| Number of Positions | 7 |
| Shell Size - Insert | M23-7 |
| Current Rating (Amps) | 20A |
| Operating Temperature | -40°C ~ 125°C |
| Contact Finish - Mating | Gold |
| Backshell Material, Plating | - |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Mating | - |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $20.52 | $20.11 | $19.71 |
Request Quote
