Image is for reference only , See Product Specifications
97C04ST
| Manufacturers: | Grayhill, Inc. |
|---|---|
| Product Category: | DIP Switches |
| Data Sheet: | 97C04ST |
| Description: | SWITCH SLIDE DIP SPST 25MA 24V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Grayhill, Inc. |
| Product Category | DIP Switches |
| Pitch | 0.050" (1.27mm), Half |
| Length | 0.248" (6.31mm) |
| Series | 97 |
| Circuit | SPST |
| Features | Tape Seal |
| Washable | Yes |
| Packaging | Tube |
| Part Status | Active |
| Actuator Type | Slide (Standard) |
| Body Material | Polyamide (PA), Nylon |
| Mounting Type | Surface Mount |
| Actuator Level | Flush, Recessed |
| Contact Finish | Gold |
| Voltage Rating | 24VDC |
| Electrical Life | - |
| Mechanical Life | 1,000 Cycles |
| Contact Material | Copper Alloy |
| Termination Style | Gull Wing |
| Height Above Board | 0.063" (1.60mm) |
| Number of Positions | 4 |
| Current Rating (Amps) | 25mA |
| Operating Temperature | -40°C ~ 85°C |
In Stock 6885 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.34 | $2.29 | $2.25 |
