Image is for reference only , See Product Specifications
94HAB10W
| Manufacturers: | Grayhill, Inc. |
|---|---|
| Product Category: | DIP Switches |
| Data Sheet: | 94HAB10W |
| Description: | SWITCH ROTARY DIP BCD 100MA 50V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Grayhill, Inc. |
| Product Category | DIP Switches |
| Pitch | 0.100" (2.54mm), Full |
| Length | 0.390" (9.91mm) |
| Series | 94H |
| Circuit | BCD |
| Features | Sealed |
| Washable | Yes |
| Packaging | Tube |
| Part Status | Obsolete |
| Actuator Type | Rotary for Tool |
| Body Material | Plastic |
| Mounting Type | Surface Mount |
| Actuator Level | Flush, Recessed |
| Contact Finish | Gold |
| Voltage Rating | 50VDC |
| Electrical Life | - |
| Mechanical Life | 10,000 Cycles |
| Contact Material | Copper Alloy |
| Termination Style | Gull Wing |
| Height Above Board | 0.225" (5.72mm) |
| Number of Positions | 10 |
| Current Rating (Amps) | 100mA |
| Operating Temperature | -40°C ~ 85°C |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
Request Quote
