Image is for reference only , See Product Specifications
SD7030-7R3-R
| Manufacturers: | Eaton-Electronics Division |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | SD7030-7R3-R |
| Description: | FIXED IND 7UH 2.3A 54 MOHM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Eaton-Electronics Division |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | SD7030 |
| Ratings | - |
| Q @ Freq | - |
| Packaging | Cut Tape (CT) |
| Shielding | Shielded |
| Tolerance | ±30% |
| Inductance | 7µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | Ferrite |
| Size / Dimension | 0.276" L x 0.276" W (7.00mm x 7.00mm) |
| DC Resistance (DCR) | 54mOhm Max |
| Current - Saturation | 2.1A |
| Current Rating (Amps) | 2.3A |
| Height - Seated (Max) | 0.118" (3.00mm) |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | - |
| Inductance Frequency - Test | 100kHz |
In Stock 1477 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.07 | $2.03 | $1.99 |
Request Quote
