Image is for reference only , See Product Specifications
PTR060V0135-BK
| Manufacturers: | Eaton-Electronics Division |
|---|---|
| Product Category: | PTC Resettable Fuses |
| Data Sheet: | PTR060V0135-BK |
| Description: | PTC RESET FUSE 60V 1.35A RADIAL |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Eaton-Electronics Division |
| Product Category | PTC Resettable Fuses |
| Type | Polymeric |
| Series | PolyTron™, PTR060V |
| Ratings | - |
| Approvals | cURus, TUV |
| Packaging | Bulk |
| Part Status | Active |
| Lead Spacing | 0.197" (5.00mm) |
| Time to Trip | 9.6s |
| Current - Max | 40A |
| Mounting Type | Through Hole |
| Voltage - Max | 60V |
| Package / Case | Radial, Disc |
| Thickness (Max) | - |
| Size / Dimension | 0.571" Dia x 0.118" T (14.50mm x 3.00mm) |
| Current - Trip (It) | 2.7A |
| Height - Seated (Max) | 0.772" (19.60mm) |
| Operating Temperature | -40°C ~ 85°C |
| Current - Hold (Ih) (Max) | 1.35A |
| Resistance - Initial (Ri) (Min) | 120 mOhms |
| Resistance - Post Trip (R1) (Max) | 300 mOhms |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.31 | $0.30 | $0.30 |
