Image is for reference only , See Product Specifications
PTR030V0900-TR1
| Manufacturers: | Eaton-Electronics Division |
|---|---|
| Product Category: | PTC Resettable Fuses |
| Data Sheet: | PTR030V0900-TR1 |
| Description: | PTC RESET FUSE 30V 9A RADIAL |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Eaton-Electronics Division |
| Product Category | PTC Resettable Fuses |
| Type | Polymeric |
| Series | PolyTron™, PTR030V |
| Ratings | - |
| Approvals | cURus, TUV |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Lead Spacing | 0.394" (10.00mm) |
| Time to Trip | 20s |
| Current - Max | 100A |
| Mounting Type | Through Hole |
| Voltage - Max | 30V |
| Package / Case | Radial, Disc |
| Thickness (Max) | - |
| Size / Dimension | 0.949" L x 0.118" W (24.10mm x 3.00mm) |
| Current - Trip (It) | 18A |
| Height - Seated (Max) | 1.346" (34.20mm) |
| Operating Temperature | -40°C ~ 85°C |
| Current - Hold (Ih) (Max) | 9A |
| Resistance - Initial (Ri) (Min) | 5 mOhms |
| Resistance - Post Trip (R1) (Max) | 20 mOhms |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.44 | $0.43 | $0.42 |
