Image is for reference only , See Product Specifications
PTR016V0075-BK
| Manufacturers: | Eaton-Electronics Division |
|---|---|
| Product Category: | PTC Resettable Fuses |
| Data Sheet: | PTR016V0075-BK |
| Description: | PTC RESET FUSE 16V 750MA RADIAL |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Eaton-Electronics Division |
| Product Category | PTC Resettable Fuses |
| Type | Polymeric |
| Series | PolyTron™, PTR016V |
| Ratings | - |
| Approvals | TUV |
| Packaging | Bulk |
| Part Status | Obsolete |
| Lead Spacing | - |
| Time to Trip | 400ms |
| Current - Max | 40A |
| Mounting Type | Through Hole |
| Voltage - Max | 16V |
| Package / Case | Radial, Disc |
| Thickness (Max) | - |
| Size / Dimension | - |
| Current - Trip (It) | 1.5A |
| Height - Seated (Max) | - |
| Operating Temperature | -40°C ~ 85°C |
| Current - Hold (Ih) (Max) | 750mA |
| Resistance - Initial (Ri) (Min) | 110 mOhms |
| Resistance - Post Trip (R1) (Max) | 230 mOhms |
