Image is for reference only , See Product Specifications
MPI4015V2-3R3-R
| Manufacturers: | Eaton-Electronics Division |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | MPI4015V2-3R3-R |
| Description: | FIXED IND 3.3UH 3A 82 MOHM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Eaton-Electronics Division |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | MPI40-V2 |
| Ratings | - |
| Q @ Freq | - |
| Packaging | Digi-Reel® |
| Shielding | Shielded |
| Tolerance | ±20% |
| Inductance | 3.3µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 2-SMD |
| Material - Core | Metal Composite |
| Size / Dimension | 0.160" L x 0.171" W (4.06mm x 4.35mm) |
| DC Resistance (DCR) | 92mOhm Max |
| Current - Saturation | 3.2A |
| Current Rating (Amps) | 3A |
| Height - Seated (Max) | 0.059" (1.50mm) |
| Operating Temperature | -55°C ~ 125°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | 31MHz |
| Inductance Frequency - Test | 100kHz |
