Image is for reference only , See Product Specifications
HCP0703-8R2-R
| Manufacturers: | Eaton-Electronics Division |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | HCP0703-8R2-R |
| Description: | FIXED IND 8.2UH 4A 68 MOHM SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Eaton-Electronics Division |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | HCP0703 |
| Ratings | - |
| Q @ Freq | - |
| Packaging | Cut Tape (CT) |
| Shielding | Shielded |
| Tolerance | ±20% |
| Inductance | 8.2µH |
| Part Status | Obsolete |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | Iron Powder |
| Size / Dimension | 0.287" L x 0.276" W (7.30mm x 7.00mm) |
| DC Resistance (DCR) | 68mOhm Max |
| Current - Saturation | 7.5A |
| Current Rating (Amps) | 4A |
| Height - Seated (Max) | 0.118" (3.00mm) |
| Operating Temperature | -55°C ~ 125°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | - |
| Inductance Frequency - Test | 100kHz |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
