Image is for reference only , See Product Specifications
HC8-100-R
| Manufacturers: | Eaton-Electronics Division |
|---|---|
| Product Category: | Fixed Inductors |
| Data Sheet: | HC8-100-R |
| Description: | FIXED IND 10UH 5.2A 43.6 MOHM |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Eaton-Electronics Division |
| Product Category | Fixed Inductors |
| Type | Wirewound |
| Series | HC8 |
| Ratings | - |
| Q @ Freq | - |
| Packaging | Digi-Reel® |
| Shielding | Unshielded |
| Tolerance | ±20% |
| Inductance | 10µH |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Material - Core | Iron Powder |
| Size / Dimension | 0.429" L x 0.409" W (10.90mm x 10.40mm) |
| DC Resistance (DCR) | 43.6mOhm Max |
| Current - Saturation | 9.2A |
| Current Rating (Amps) | 5.2A |
| Height - Seated (Max) | 0.157" (4.00mm) |
| Operating Temperature | -40°C ~ 155°C |
| Supplier Device Package | - |
| Frequency - Self Resonant | - |
| Inductance Frequency - Test | 100kHz |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.00 | $0.00 | $0.00 |
