CTX8-1-R
| Manufacturers: | Eaton-Electronics Division |
|---|---|
| Product Category: | Arrays, Signal Transformers |
| Data Sheet: | CTX8-1-R |
| Description: | INDUCT ARRAY 2 COIL 8.1UH SMD |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Eaton-Electronics Division |
| Product Category | Arrays, Signal Transformers |
| Height | 0.165" (4.19mm) |
| Series | OCTA-PAC® |
| Ratings | - |
| Packaging | Tape & Reel (TR) |
| Shielding | Unshielded |
| Tolerance | ±20% |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Number of Coils | 2 |
| Size / Dimension | 0.450" L x 0.450" W (11.43mm x 11.43mm) |
| Operating Temperature | -40°C ~ 85°C |
| Current Rating - Series | 1A |
| Current Rating - Parallel | 2A |
| DC Resistance (DCR) - Series | 157mOhm Max |
| DC Resistance (DCR) - Parallel | 39mOhm Max |
| Inductance - Connected In Series | 32.4µH |
| Inductance - Connected In Parallel | 8.1µH |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $2.44 | $2.39 | $2.34 |
