Image is for reference only , See Product Specifications
CB20112607
| Manufacturers: | Eaton-Electronics Division |
|---|---|
| Product Category: | Terminal Blocks - Barrier Blocks |
| Data Sheet: | CB20112607 |
| Description: | CONN BARRIER STRP 26CIRC 0.375" |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | Eaton-Electronics Division |
| Product Category | Terminal Blocks - Barrier Blocks |
| Color | Black |
| Pitch | 0.375" (9.53mm) |
| Series | Magnum® CB2000 |
| Features | Flange |
| Packaging | Bulk |
| Wire Gauge | 12-22 AWG |
| Part Status | Active |
| Barrier Type | 3 Wall (Tri) |
| Mounting Type | Chassis, Panel |
| Number of Rows | 1 |
| Voltage Rating | 300V |
| Top Termination | Screws with Captive Plate |
| Bottom Termination | Solder Turret |
| Number of Circuits | 26 |
| Terminal Block Type | Barrier Block |
| Current Rating (Amps) | 30A |
| Material - Insulation | Thermoplastic |
| Operating Temperature | -40°C ~ 105°C |
| Terminal Screw Finish | Zinc |
| Number of Wire Entries | 26 |
| Terminal Screw Material | Steel |
| Material Flammability Rating | UL94 V-0 |
In Stock 50 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $13.84 | $13.56 | $13.29 |
