Image is for reference only , See Product Specifications
B41580A8100M000
| Manufacturers: | EPCOS (TDK) |
|---|---|
| Product Category: | Aluminum Electrolytic Capacitors |
| Data Sheet: | B41580A8100M000 |
| Description: | CAP ALUM 100000UF 20% 63V SCREW |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | EPCOS (TDK) |
| Product Category | Aluminum Electrolytic Capacitors |
| Series | B41580 |
| Ratings | - |
| Impedance | 6.6 mOhms |
| Packaging | Bulk |
| Tolerance | ±20% |
| Capacitance | 100000µF |
| Part Status | Active |
| Applications | General Purpose |
| Lead Spacing | 1.248" (31.70mm) |
| Polarization | Polar |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Voltage - Rated | 63V |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Size / Dimension | 3.028" Dia (76.90mm) |
| Height - Seated (Max) | 5.677" (144.20mm) |
| Operating Temperature | -40°C ~ 105°C |
| Surface Mount Land Size | - |
| Ripple Current @ Low Frequency | 23A @ 100Hz |
| ESR (Equivalent Series Resistance) | 5mOhm @ 100Hz |
In Stock 13 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $91.20 | $89.38 | $87.59 |
