Image is for reference only , See Product Specifications
B41560A9159M000
| Manufacturers: | EPCOS (TDK) |
|---|---|
| Product Category: | Aluminum Electrolytic Capacitors |
| Data Sheet: | B41560A9159M000 |
| Description: | CAP ALUM 15000UF 20% 100V SCREW |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | EPCOS (TDK) |
| Product Category | Aluminum Electrolytic Capacitors |
| Series | B41560 |
| Ratings | - |
| Impedance | 10 mOhms |
| Packaging | Bulk |
| Tolerance | ±20% |
| Capacitance | 15000µF |
| Part Status | Active |
| Applications | General Purpose |
| Lead Spacing | 1.122" (28.50mm) |
| Polarization | Polar |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Voltage - Rated | 100V |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Size / Dimension | 2.532" Dia (64.30mm) |
| Height - Seated (Max) | 4.161" (105.70mm) |
| Operating Temperature | -40°C ~ 105°C |
| Surface Mount Land Size | - |
| Ripple Current @ Low Frequency | 15A @ 100Hz |
| ESR (Equivalent Series Resistance) | 10mOhm @ 100Hz |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $52.60 | $51.55 | $50.52 |
