Image is for reference only , See Product Specifications
TL1105WF160R
| Manufacturers: | E-Switch |
|---|---|
| Product Category: | Tactile Switches |
| Data Sheet: | TL1105WF160R |
| Description: | SWITCH TACTILE SPST-NO 0.05A 50V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | E-Switch |
| Product Category | Tactile Switches |
| Series | TL1105 |
| Circuit | SPST-NO |
| Outline | 7.10mm x 6.55mm |
| Features | - |
| Packaging | Bulk |
| Part Status | Active |
| Illumination | Non-Illuminated |
| Actuator Type | Standard |
| Mounting Type | Through Hole, Right Angle |
| Switch Travel | 0.25mm |
| Mechanical Life | 100,000 Cycles |
| Operating Force | 160gf |
| Switch Function | Off-Mom |
| Actuator Material | Polyamide (PA), Nylon |
| Termination Style | PC Pin |
| Ingress Protection | - |
| Actuator Orientation | Side Actuated |
| Operating Temperature | -20°C ~ 70°C |
| Contact Rating @ Voltage | 0.05A @ 50VDC |
| Illumination Type, Color | - |
| Actuator Length, Right Angle | 3.15mm |
| Illumination Voltage (Nominal) | - |
| Actuator Height off PCB, Vertical | - |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.77 | $0.75 | $0.74 |
