TL1014BF180QG
| Manufacturers: | E-Switch |
|---|---|
| Product Category: | Tactile Switches |
| Data Sheet: | TL1014BF180QG |
| Description: | SWITCH TACTILE SPST-NO 0.05A 12V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | E-Switch |
| Product Category | Tactile Switches |
| Series | TL1014 |
| Circuit | SPST-NO |
| Outline | 6.40mm x 3.50mm |
| Features | Board Guide |
| Packaging | Digi-Reel® |
| Part Status | Obsolete |
| Illumination | Non-Illuminated |
| Actuator Type | Rectangular Button |
| Mounting Type | Surface Mount, Right Angle |
| Switch Travel | 0.30mm |
| Mechanical Life | 100,000 Cycles |
| Operating Force | 180gf |
| Switch Function | Off-Mom |
| Actuator Material | Polyamide (PA46), Nylon 4/6 |
| Termination Style | Gull Wing |
| Ingress Protection | - |
| Actuator Orientation | Side Actuated |
| Operating Temperature | -20°C ~ 70°C |
| Contact Rating @ Voltage | 0.05A @ 12VDC |
| Illumination Type, Color | - |
| Actuator Length, Right Angle | - |
| Illumination Voltage (Nominal) | - |
| Actuator Height off PCB, Vertical | - |
