PV7F2T0SS-301
| Manufacturers: | E-Switch |
|---|---|
| Product Category: | Pushbutton Switches |
| Data Sheet: | PV7F2T0SS-301 |
| Description: | SWITCH PUSHBUTTON DPST 2A 48V |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | E-Switch |
| Product Category | Pushbutton Switches |
| Type | Vandal Resistant, Illuminated |
| Series | PV7, LAMB |
| Circuit | DPST-NO/NC |
| Features | - |
| Packaging | Bulk |
| Part Status | Active |
| Actuator Type | Round, Button, Flush |
| Mounting Type | Panel Mount, Front |
| Electrical Life | 50,000 Cycles |
| Mechanical Life | 1,000,000 Cycles |
| Switch Function | On-Off, Off-On |
| Termination Style | Solder, Quick Connect - 0.110" (2.8mm) |
| Ingress Protection | IP65 - Dust Tight, Water Resistant |
| Voltage Rating - DC | 48V |
| Color - Actuator/Cap | Silver |
| Current Rating (Amps) | 2A (DC) |
| Operating Temperature | -20°C ~ 55°C |
| Panel Cutout Dimensions | Circular - 22.00mm Dia |
| Illumination Type, Color | LED, White |
| Illumination Voltage (Nominal) | 2.8 VDC |
In Stock 103 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $21.69 | $21.26 | $20.83 |
